EL-Replacements
In many small displays you can find EL-panels as a backlight, such as:
AND711A, Displaytronic ACM5502A, Hitachi LMG6401PLGE, Optrex DMC16207-AE, Optrex DMC16249, Optrex DMF5005, Optrex DMF612, Sharp LM16155, Sharp LM24014, Sharp LM640HCN24V, Toshiba TLX 711A, Toshiba TLX 1013 EO, Yamaha NB830200
And in many electronic devices, especially music devices, too:
Akai ASQ-10, MPC60 version 1, MPC60II, MPC3000, PB1000, S1000, S1100, S2800, S3000(XL), S3200(XL), S950, SP12, SP1200, VX600
ART Multiverb III
Böhm MD 1000, 1030, 2000, Diamant 300/350, 400/450
Casio CZ-1, FZ-1, FZ-10, FZ-10M, FZ-20M, VZ-1, VZ-10M
Dynacord ADD-one
ELKA EK33, EM33, ER33, EK44, EM44, ER44
EMU EIII, EIIIX, EMAX I and II, Emulator II, III and IV, E-4, E-64, ESi-32, SP12
HITEC AC-1
Hohner HS-1, HS-1E, HS-10, HS-10M, HS-2/E, HS-20M
Kawai K5, K5m, K5000R, Z1000
Klark Teknik DN3600
Korg 01 W, 01 WFD, 03 R/W, i3, A2, A3, DRV-2000, DS-8, M1, M1 Rex, N264, N364, Re1, T1, T2, T3, X3, X3-r, Wave Station AD, Wavestation EX, Wavestation WS1
Kurzweil K1200, K2000
Lexicon MRC
Mackie MCU Pro
Massey-Ferguson Datatronic II 6100 + 8100
Positec Vorschubsteuerung PSS 150
PPG 2.3
Roland Alpha Juno 1 and 2, A-50, A-80, D-50, D-550, D-70, DM80R, DM800, E-96, GC-8, MKS-20, MKS-80, MKS-100, MC500 MKII, MV-30, PG1000, S-10, S750, S770, VK1000, W-30
Sequential Circuits Prophet VS
Sewing Machines Brother Super Galaxie 895, PC7500, Elna 9007, Esante ESi-2, Janome MC5000, MC5700, MC8000, Privileg Computer Star 7000, 7100
TC 1128
Waldorf Wave Synthesizer
WERSI Pegasus, Performer, PhonX, Phoenix, Rondo, CD Orgeln with Golden Gate
Yamaha DEQ 5, QS300, REV-7, SY-77, SY-99, TG-77, W5, W7
and many more.
The brightness of EL based backlights can not compete with daylight, CCFL or LED, of course. But the target application can be found in twilight and darkness. E.g. displays of music machines and handheld computers, controls and instruments, signaling, clocks, etc.
A great advantage is the small power consumption and the flexibility of the paperthin material.
Contact us +49-7754-9258890, if you don`t find your related type of backlight here!
EL-panel, azure blue, sliceable, laminated, outer dimensions(LxWxH): 15mm x 160mm x 0.33mm for Korg A2, Korg A3, Fluke PM2813
EL-panel, azure blue, sliceable, laminated, outer dimensions(LxWxH): 18mm x 74mm x 0.42mm for LCDs in ART Multiverb III, ELKA EK33, EK44, EM33, EM44, ER33, ER44, E-MU EMAX I and II, Emulator II, SP12, SP1200, Korg DRV-2000, Kurzweil K1200, Roland Alpha Juno 1 and 2, Roland MKS-80, Roland PG1000, Sequential Circuits Prophet VS, Yamaha REV-7 and suitable for LCD Optrex DMC16207-AE DMC 16249, SHARP LCD LM16155
EL-panel, azure blue, sliceable, laminated, outer dimensions(LxWxH): 21mm x 166mm x 0.33mm for Akai Sampler S950, Drawmer M500, Dynacord ADD-one, HITEC AC-1 (cut), Korg 03 R/W, DS8, M1, M1 Rex, Re1, M3R, Lexicon MRC (cut), Positec PSS 150, PPG 2.3 (cut), Roland D-50, D-550 and Sharp LM640HCN24V
EL-panel, azure blue, sliceable, laminated, outer dimensions(LxWxH): 30mm x 94mm x 0.42mm for LCDs of E-MU EIII, EMU Emulator III
EL-panel, azure blue, sliceable, laminated, outer dimensions(LxWxH): 33mm x 224mm x 0.33mm for doorsteps of Mercedes car. e.g. G500.
EL-panel, azure blue, laminated, sliceable, outer dimensions(LxWxH): 40mm x 132mm x 0.33mm for Akai VX600, MPC60II
EL-panel, azure blue, sliceable, laminated, outer dimensions(LxWxH): 43mm x 155mm x 0.33mm for LCD Optrex DMF5005, AND711A, Toshiba TLX 711A, Korg i3, Korg Wavestation A/D, Korg Wavestation EX Korg Wavestation WS1, Korg Wavestation WSA/D, Roland A-50, Roland A80, Roland D-70, Roland GC-8, Yamaha DEQ 5, Yamaha QS300, Yamaha SY-77, Yamaha SY-99, Yamaha W5, Yamaha W7
EL-panel, azure blue, laminated, sliceable, outer dimensions(LxWxH): 47mm x 157mm x 0.33mm for LCD Optrex DMF5005, LCD Sharp LM24014, Akai MPC60 version 1, ASQ-10, EMU Emulator IV, Korg 01 R, 01W, 01 WFD, T1, T2, T3, Kurzweil K2000(r), Roland DM80R, DM800, S750, S770, W-30
EL-panel, blue-green, sliceable, laminated, outer dimensions(LxWxH): 18mm x 74mm x 0.42mm for LCDs in ART Multiverb III, ELKA EK33, EK44, EM33, EM44, ER33, ER44, E-MU EMAX I and II, Emulator II, SP12, SP1200, Korg DRV-2000, Kurzweil K1200, Roland Alpha Juno 1 and 2, Roland MKS-80, Roland PG1000, Sequential Circuits Prophet VS, Yamaha REV-7 and suitable for LCD Optrex DMC16207-AE, DMC16249, SHARP LCD LM16155
EL-panel, blue-green, sliceable, laminated, outer dimensions(LxWxH): 21mm x 166mm x 0.33mm for Akai Sampler S950, Drawmer M500, Dynacord ADD-one, HITEC AC-1 (cut), Korg 03 R/W, DS8, M1, M1 Rex, Re1, M3R, Lexicon MRC (cut), Positec PSS 150, PPG 2.3 (cut), Roland D-50, D-550 and Sharp LM640HCN24V
EL-panel, blue-green, incl. attached cables and connector, laminated, sliceable, outer dimensions(LxWxH): 24mm x 80mm x 0.42mm, backlight for Casio CZ-1
EL-panel, blue-green, sliceable, laminated, outer dimensions(LxWxH): 24mm x 96mm x 0.42mm for LCDs of Korg DSS-1, REVOX B226-S, Roland MKS-20
EL-panel, blue-green, sliceable, laminated, outer dimensions(LxWxH): 30mm x 94mm x 0.42mm for LCDs of E-MU EIII, EMU Emulator III, Graphic Equalizer TC 1128 (cut)
EL-panel, blue-green, laminated, sliceable, outer dimensions(LxWxH): 41mm x 66mm x 0.42mm, backlight for Casio FZ-10, FZ-10M, FZ-20M, VZ-1, VZ-10M, Hohner HS-10, HS-10M, HS-20M, HS2/E
EL-panel, blue-green, sliceable, laminated, outer dimensions(LxWxH): 43mm x 155mm x 0.33mm for LCD Optrex DMF5005, AND711A, Toshiba TLX 711A, Kawai K5m, Korg i3, Korg Wavestation A/D, Korg Wavestation EX, Korg Wavestation WS1, Korg Wavestation WSA/D, Roland A-50, Roland A80, Roland D-70, Roland GC-8, Yamaha DEQ 5, Yamaha QS300, Yamaha SY-77, Yamaha SY-99, Yamaha W5, Yamaha W7
EL-panel, blue-green, incl. attached cables and connector, laminated, sliceable, outer dimensions(LxWxH): 46mm x 67mm x 0.42mm, backlight for Casio FZ-1, Hohner HS-1, HS-1E
EL-panel, blue-green, laminated, sliceable, outer dimensions(LxWxH): 47mm x 157mm x 0.33mm for LCD Optrex DMF5005, LCD Sharp LM24014, Yamaha NB830200, Akai MPC60 version 1, ASQ-10, EMU Emulator IV, Korg 01 R, 01W, 01 WFD, T1, T2, T3, Kurzweil K2000(r), Roland DM80R, DM800, S750, S770, W-30, Yamaha RCR-1
EL-panel, green, laminated, sliceable, outer dimensions(LxWxH): 93mm x 135mm x 0.45mm for general backlighting purpose
EL-panel, pink-white, sliceable, laminated, outer dimensions(LxWxH): 18mm x 74mm x 0.42mm for LCDs in ELKA EK33, EK44, EM33, EM44, ER33, ER44, E-MU EMAX I and II, Emulator II, SP12, SP1200, Korg DRV-2000, Kurzweil K1200, Roland Alpha Juno 1 and 2, Roland MKS-80 and MKS-100, Roland PG1000, Roland S-10, Sequential Circuits Prophet VS, Yamaha REV-7 and suitable for LCD Optrex DMC16207-AE, SHARP LCD LM16155
EL-panel, pink-white, laminated, sliceable, outer dimensions (LxWxH): 19.5mm x 222mm x 0.33mm for Displaytronic ACM5502A, Emagic Logic Control, Mackie Control, Mackie MCU Pro
EL-panel, pink-white, sliceable, laminated, outer dimensions(LxWxH): 24mm x 96mm x 0.42mm for LCDs of Brother KH970 control panel CB 1, Roland MC500 MKII, Sony HR MP5
EL-panel, pink-white, laminated, sliceable, outer dimensions(LxWxH): 28mm x 108mm x 0.44mm, backlight for LCD Powertip PC 1602-L
EL-panel, pink-white, laminated, sliceable, outer dimensions(LxWxH): 30mm x 89mm x 0.42mm, backlight for EMU ESi-32
EL-panel, pink-white, laminated, sliceable, outer dimensions(LxWxH): 32mm x 89mm x 0.42mm, backlight for EMU EIIIX
EL-panel, pink-white, laminated, sliceable, outer dimensions (LxWxH): 39mm x 93mm x 0.42mm, backlight for Korg N264, Korg N364, Korg X3, Korg X3-r, Roland E660 EQ
EL-panel, pink-white, laminated, sliceable, outer dimensions(LxWxH): 40mm x 132mm x 0.33mm for Akai PB1000, HD1000, S1000, S1100, S1200, S2800, S2800i, S3000, S3000XL, S3000i, CD3000, CD3000XL, CD3000i, S3200, S3200XL, VX600, MPC3000, MPC60II
EL-panel, pink-white, laminated, sliceable, outer dimensions (LxWxH): 41mm x 254mm x 0.45mm for LCD Optrex DMF612, Graphic Equalizer Klark Teknik DN3600, Waldorf Wave Synthesizer
EL-panel, pink-white, with cables, outer dimensions(LxWxH): 43mm x 130mm x 0.33mm for the display of sewing machine Brother Super Galaxie 895, PC7500, Elna 9007, Esante ESi-2, Janome MC5000, MC5700, MC8000, Privileg Computer Star 7000, 7100
EL-panel, pink-white, sliceable, laminated, outer dimensions(LxWxH): 43mm x 155mm x 0.33mm for LCD Optrex DMF5005, AND711A, Toshiba TLX 711A, Epson EG2401S-KR, Beolink7000 (cut), Kawai K5000R+S, Kawai Z1000, Korg i3, Korg Wavestation A/D, Korg Wavestation EX, Korg Wavestation WS1, Korg Wavestation WSA/D, Roland A-50, Roland A-80,Roland D-70, Roland E-96, Roland G-800, Roland GC-8, Roland MV30 (cut), Roland VK1000, Yamaha DEQ 5, Yamaha SY-77, Yamaha SY-99, Yamaha TG-77, Yamaha W7
EL-panel, pink-white, laminated, sliceable, outer dimensions(LxWxH): 47mm x 157mm x 0.33mm for LCD Optrex DMF5005, LCD Sharp LM24014, Akai MPC60 version 1, ASQ-10, EMU Emulator IV, Kawai K5, Korg 01 R, 01 W, 01 WFD, T1, T2, T3, Kurzweil K2000(r), Roland DM80R, DM800, S750, S770, W-30
EL-panel, pink-white, laminated, sliceable, outer dimensions(LxWxH): 48mm x 166mm x 0.33mm for Böhm MD 1000, 1030, 2000, Böhm Diamant 300/350, 400/450, LCD Seiko L4044 (as cut).
EL-panel, pink-white, laminated, sliceable, outer dimensions(LxWxH): 52mm x 155mm x 0.33mm for EMU E4, EMU E-64
EL-panel, pink-white, laminated, sliceable, outer dimensions(LxWxH): 67mm x 123mm x 0.49mm for WERSI Pegasus, Performer, PhonX, Phoenix, Rondo, CD Orgeln with Golden Gate
EL-panel, pink-white, laminated, sliceable, outer dimensions (LxWxH): 80mm x 143.5mm x 0.33mm for Hitachi LMG6401PLGE
EL-panel, pink-white, laminated, sliceable, outer dimensions(LxWxH): 87mm x 112mm x 0.33mm for Massey-Ferguson Datatronic II 6100, 8100, Toshiba TLX-1013-EO
EL-panel, softyellow (= better contrast), sliceable, laminated, outer dimensions(LxWxH): 15mm x 160mm x 0.33mm for Korg A2, Korg A3
EL-panel, softyellow (= better contrast), sliceable, laminated, outer dimensions(LxWxH): 18mm x 74mm x 0.42mm for LCDs in ELKA EK33, EK44, EM33, EM44, ER33, ER44, E-MU EMAX I and II, Emulator II, SP12, SP1200, Korg DRV-2000, Kurzweil K1200, Roland Alpha Juno 1 and 2, Roland MKS-80, Roland PG1000, Sequential Circuits Prophet VS, Yamaha REV-7 and suitable for LCD Optrex DMC16207-AE, SHARP LCD LM16155
EL-panel, softyellow(= better contrast), sliceable, laminated, outer dimensions(LxWxH): 40mm x 132mm x 0.33mm for Akai VX600, MPC60II
EL-panel, softyellow (= better contrast), laminated, sliceable, outer dimensions(LxWxH): 41mm x 66mm x 0.42mm, backlight for Casio FZ-10, FZ-10M, FZ-20M, VZ-1, VZ-10M, Hohner HS-10, HS-10M, HS-20M, HS2/E
EL-panel, softyellow (= better contrast), sliceable, laminated, outer dimensions(LxWxH): 43mm x 155mm x 0.33mm for LCD Optrex DMF5005, AND711A, Toshiba TLX 711A, Korg i3, Korg Wavestation A/D, Korg Wavestation EX, Korg Wavestation WS1, Korg Wavestation WSA/D, Roland A-50, Roland A80, Roland D-70, Roland GC-8, Yamaha DEQ 5, Yamaha, QS300, Yamaha SY-77, Yamaha SY-99, Yamaha TG-77, Yamaha W5, Yamaha W7
